Portable Type2 Homeuse Smart EV Charger 7kW|CEE 3-Pin|5M(16.5ft)
-
Inc. GST 10%
Couldn't load pickup availability
- This charger allows to charge your EVs and PHEVs with Type 2 charging connector easily and conveniently.
- 15A strong current with 3.5KW(max) high power allows quick and efficient charging, plug and play.
- It is available to provide corresponding current to match with different EVs and PHEVs.
- Support intelligent security lock function and smart temperature control.
- The control box provides an 2.4" LCD screen & Indicator Light to show parameters (R/G/B) , allowing you to understand the working status of the charger.
- Our products have a matching APP—Smart Life APP, which can schedule charging, check charging status, disconnect power, etc.
- Made of highly flame-retardant and high strength material, secure and durable.
- RCD Protection:
- Type A(30mA AC)
- IP65, Weather proof;
- Leakage current protection;
- Impact resistance;
- Over current protection;
- Ground protection;
- Surge protection;
- O/U voltage protection;
- O/U frequency protection;
- Over temp protection.
Compatible Models and Years:
Universal for all Electric Vehicles (EVs) and Plug In Hybrid Electric Vehicles (PHEVs) that use a Type 2 charging connector.
EV Charger Care Guide
Good care helps protect charging performance and reduces preventable faults.
Before every charge
Check the plug, socket, cable and control box for cracks, burn marks, loose parts, water or dirt. Do not use the charger if anything looks damaged.
During charging
Keep the cable uncoiled where possible, avoid tight bends, and keep the control box away from standing water, heat sources and heavy objects. Do not cover the control box while charging.
Storage
After use, disconnect safely, let the cable cool if needed, wipe off dust or moisture, and store it in a dry place away from direct sunlight and sharp edges.
When to stop using it
Stop immediately if charging is unstable, the plug becomes unusually hot, you smell burning, or the cable/control box shows damage. Contact us with photos or video before using it again.
Delivery Information
We aim to make delivery expectations clear before you place your order.
Dispatch time
Orders are usually prepared and shipped within 48 hours after order confirmation, excluding weekends, public holidays and exceptional carrier delays.
Estimated delivery time
Estimated arrival is generally 7-12 business days. Remote areas may take longer. Tracking information will be provided when available.
Before signing or opening
Please check the parcel condition when it arrives. If packaging is badly damaged, take photos before opening and contact us promptly so we can help.
What is in the parcel
Parcel contents vary by product. Please check the specific product page for the included charger, cable, plug type and any accessories before ordering.
Product details
| Model Number | EV-B2-32AC-BK/WH5M |
| Condition | 100% Brand New |
| Brand Name | MotiveX |
| Place Of Origin | Australia |
| Protection Rank | IP65/66 |
| Connector Type | IEC 62196 Type2 |
| Amperage | Adjustable 32A |
| Output Power | 7 KW |
| Cable Length | 5M（16.5ft） |
| Operating Voltage | AC 200-250V(1 Phase) |
| AC Input Plug | CEE 3-Pin |
| LCD display | 2.4 Inches LCD Screen |
| Charging Method | Plug & Play |
| Communication Method | WiFi & Bluetooth |
| Appearance Size | L220*W100*H60mm |
| Operating Temperature | -35℃ to +50℃ |
| Operating Humidity | 5% ~ 95%HR |
| Insulation Resistance | ≥100MΩ |
| Packages | Each in PE bag, then in shipping box. Protect the transportation and storage of products. |
| Certificate | CE, UKCA, ROHS, ISO, TUV, CB, FCC |
| Warranty | 2 Years |
| Leakage Protection | CCID20, Leakage, The Relay Was Off |
| Ground Protection | The Ground Wire Is Not Detected Or The Ground Wire Is Disconnected During Charging. The Relay Is Disconnected. |
| Over Temperature Protection | When the Temperature of The Main Board Reached 185℉, The Power was Reduced to 50%, and It was Turned Off After 194℉ |
